Torsion Testing Machine (100Nm)

Product Description

Description of Torsion Testing Machine (100Nm)

Torsion Testing Machine for manually applying torque to test specimens until failure occurs. Torque is applied to differing material test specimens using hand operated gearbox. The input angle of twist is recorded on an integral protractor and a rotary potentiometer that connects to the Data Acquisition Interface supplied. Test specimens of up to 350mm can be loaded between the torsion head and fixing head using standard hexagon drives. The fixing head slides along the base. The Torsion Testing Machine exhibited to the test specimen is measured using strain gauge technology. The output from the strain gauges is fed directly into the Data Acquisition Interface supplied, which reads torsion directly in Nm.

Experimental capabilities of Torsion Testing Machine (100Nm)

1. Torsional loading to failure of varying material specimens
2. Torsional variation due to material, cross sectional area
3. Comparison between actual and theoretical results
4. Determination of the Modulus of Rigidity and Yield shear stress
5. Working with the elastic torsion equation

Specification of Torsion Testing Machine (100Nm)

An apparatus for manually applying torque to test specimens until failure occurs. Torque is applied to differing material test specimens using hand operated gearbox.
