The Gauge Factor Of Strain Gauges

Product Description

Features:

1. Measurementof deflection and strain

2. Determinationof the gauge factor of strain gauges

Specification:

1. Investigationof deflection and strain to determine gauge factor

2. Bending barwith 2 strain gauges on the compression side and tension side respectively

3. Strain gaugeconfigured as full bridge

4. 2-point ballbearing mounting of bar permits purely bending load application

5. Mechanicalload application device with spindle, hand wheel and cross-arm

6. Dial gaugewith adjustable dial for direct measurement of deflection

7. Measuringamplifier with 4-digit digital display

Bending barmade of steel: 660x25x12mm

Strain gaugeapplication:

1. Full bridge,350 Ohm

2. 2 straingauges on the top and underside of the bar respectively


Measuringrange: ±2mV/V

• Resolution:1µV/V

• Zerobalancing adjustment range: ±1mV

• Supplyvoltage: 10VDC


20mm


• Graduation:0,01mm
