Fuel Cell System

Product Description

Fuel Cell System

Specification

1. Investigation of a polymer-membrane fuel cell
2. Water cooled system in combined heat and power
3. Hydrogen supplied via standard pressure vessel
4. High-pressure reducing valve for hydrogen pressure vessel supplied
5. Oxygen supplies directly from the ambient air
6. Precise adjustment of all operating points via electronic load
7. Regulation of moisture without external humidification
8. Sensors for flow rate, pressure, temperature, voltage and current strength
9. Complete operation and evaluation via a PC

Technical Data

1. Nominal output: 360W
2. Nominal operating point: 15A / 24V
3. Thermal power: approx. 480W depending on ambient conditions
4. Required ambient temperature: 5...30°C
5. Required inlet pressure: 1...200bar

Measuring ranges

1. Flow rate (cooling water): 0,6...0,7l/min
2. Flow rate (hydrogen): 1...5l/min
3. Pressure in the system (hydrogen):
4. 250...350mbar
5. Temperatures: 5...55°c
6. Voltage (stack): 20...40v
7. Current (stack): 0,1...20a
