Test Stand For Single Cylinder Engines

Product Description

Test Stand for Single Cylinder Engines, 7,5kW

1. Control and load unit for prepared single-cylinder engines (two-stroke and four-stroke) with a maximum power output of 7,5kw
2. Asynchronous motor with energy recovery unit as brake generates engine load
3. Engine started by asynchronous motor
4. Force transmission from engine to brake via elastic claw coupling
5. Vibration-insulated base plate for engine mounting
6. Stabilisation tank for intake air
7. Potentiometer for continuous adjustment of braking torque
8. Potentiometer for continuous adjustment of braking speed
9. Measurement and display of torque, air temperature, air intake quantity, negative intake pressure, speed, fuel consumption, fuel temperature
10. Measured value displays for engine: exhaust gas temperature and cooling water temperatures

Technical Data

1. Asynchronous motor as brake
2. Power output: approx. 7,5kw at 2900min-1
3. Energy recovery unit: 13kW

Measuring ranges

1. Torque: -50...50nm
2. Temperatures: 0...900°c
3. Speed: 0...5.00min-1
4. Fuel consumption: 50cm³/min
5. Engine intake pressure: -400...0mbar
6. Air consumption: 0...690L/h
