Crystallisation Unit

Product Description

Specification of Crystallisation Unit

• A benchtop unit comprising a vacuum formed ABS plastic plinth with integral electrical console onto which is mounted the stirred glass crystallisation vessel, water heater, water flow meter and heat exchanger.
• A temperature sensor and 2kW water heater mounted in the mains water line and linked to a PID controller for accurate process temperature control.
• A conductivity probe measuring solution conductivity.
• A cooling action controlled indirectly by the valved flow meter.
• Protection devices for all electrical circuits.
• Two displays: PID temperature control (reactor temperature), display for conductivity.
• Sensor signals are routed to the USB interface for connection to a PC.
• USB port for data logging by the supplied software.
• Set of sieves for Crystal Size Distribution determination.
• Comprehensive instruction manual with detailed laboratory teaching exercises.
