Three Phase Separation Trainer With DCS Control

Product Description

Three Phase Separation Trainer with DCS Control Function of Three Phase Separation Trainer with DCS Control The primary separation operation for crude oil occurs when the crude stream flows through a vessel of sufficient capacity to allow gravitational separation of the gas, liquid hydrocarbon and water phases. This process trainer blends air, water and refined oil to emulate a crude oil stream. This fluid mixture then flows into a horizontal separator vessel fabricated of clear PVC. Gas flow passes through a secondary vertical 2-phase separator. The separator is equipped with industry-typical process measurement devices. The entire trainer is controlled from an optional distributed control system or dedicated control panel. Specification of Three Phase Separation Trainer with DCS Control Clear PVC separator vessels and process piping610 x 1830 mm (24 dia. x 72) horizontal separatorElectronic process measurement and control system with 5 control loops, water-cut meters plus low/high level and pressure sensorsTwo centrifugal pumps for water and oilOil and water storage tanksComplete unit mounted on a steel structure skidApproximate dimensions of process skid 210 x 400 x 230 cm high (7 x14 x 7.5 high) Dimensions may be adjusted based on room size and layout.
