Automation Hydraulics

Product Description

HydraulicsThis Trainer Is Composed As Follows: Work bench complete with metal working panel with holes for clamping the hydraulic components without using additional tools, 4 wheels and 3 drawers for storing components.Hydraulic power unit assembled onto the metal structure, under the panel; 4.5 liters /min., noise level 60 db 1 meter, pressure relief valve, oil level viewfinder, air inlet filter, oil return filter, 1 pressure gauge, oil reservoir 30 liters, on off control box with two push buttons and motor overload protection.Pressure relief valves 2 125 bar (2 off )One way flow restrictorShut off ball valveTwo way flow restrictorT distributor with pressure gaugeCross distributor, 4 connectionsPressure compensated one way flow regulatorFour connections distributor on manifold with pressure gauge 0 .. 100 barOne way restrictor (non return valve)Double acting differential cylinderPiloted one way restrictor2/2 manual acting valve, spring return3/2 manual acting valve, spring return4/2 manual acting valve, spring return4/3 manual acting valve, spring centredSet of tubes for testing pressure dropsSet of 12 hoses with quick female connectorsWorkbook with theory and practices
