Turbine Dynamometer

Product Description

Description:

You need the Turbine Dynamometer for tests on the optionalturbines. It fits on the Centrifugal Pump Module, near the outlet end of thecentrifugal pump. You fit any of the three optional turbines to the TurbineDynamometer. Each turbine has a brake drum that fits inside the dynamometer.You connect the outlet of the centrifugal pump to your turbine. As the pumpforces water through the turbine, you use a control on the Turbine Dynamometerto adjust a band brake. This loads the turbine. The Turbine Dynamometer and itsinstrumentation then measures and displays the speed, torque and shaft poweravailable at the dynamometer. The Turbine Dynamometer instrumentation fitsabove the dynamometer, in the iInstrument frame of the Centrifugal Pump Module.

Specifications:

Nett dimensions andweights:

• Dynamometer: 550 mm x 255 mm x 110 mm and 8 kg

• Torque and speed display: 450 mm x 190 mm x 170 mm and 4 kg


Instrumentation:

• Measures and displays turbine power, speed and torque.

• Electrically powered from outlets on the UniversalDynamometer motor drive.
