Single Sided Can Bus Multiplex Trainer

The Single Sided Can Bus Multiplex Trainer that communicates in J-1939 protocol. Digital and analog inputs and outputs can be activated. Analog signals can be displayed using the J-1939 display. This unit is equipped with an integrated electronic fault box containing 12 faults.

Educational Advantages of Single Sided Can Bus Multiplex Trainer

• The Single Sided Can Bus Multiplex Trainer uses SAE J1929 communications protocol to operate a 4 module CAN Bus network, which includes both a DLC and a Deutch Connector.
• The trainer demonstrates common multiplexing circuit controls via a high speed CAN Bus network.
• Students connect modules and components using included jumper wires.
• The Single Sided Can Bus Multiplex Trainer can be used as a CAN Bus demonstration trainer, or, using the included comprehensive student lab manual, as a CAN Bus training course.
• Built in electronic fault box allows fault insertion into circuits for diagnostic training and student comprehension.

Main Features of Single Sided Can Bus Multiplex Trainer

• Single sided trainer with upgrade capacity for a double-sided configuration
• Included user manual with theory explanations of CAN Bus, student exercises, schematics, sample scope patterns and check tests
• Includes four (4) modules that replicate heavy vehicle applications including.
• Trainer can also be used to instruct basics of CAN Bus automotive.
• Includes digital and analog inputs/outputs
• Each module has test points for individual diagnosis and testing
• Jumper wire storage racks mounted to frame
• Stand has two fixed and two lockable casters for easy trainer movement
