Photovoltaic Panels Study Unit

The photovoltaic panels study unit is composed of basic panel mounted on a stand which allows any type of orientation, a movable electric equipment complete of voltmeter and ammeter, and a light source.

Characteristics of Photovoltaic Panels Study Unit

The electric instruments allow the photovoltaic panel performances control in the different conditions of solar and artificial radiation. The artificial radiation is possible because there is a light source constituted by lamp with brightness continuous change gear (0·300 W) mounted on an adjustable tripod. The panel is constituted by 36 single-crystalline silicon cells, connected in series, and  It presents the following characteristics with an ambience temperature of +25C:

• Peak Watts: 10 W
• Peak power voltage: 17 V
• Amps max: 600 mA
• Open-circuit voltage: 22 V

Required services of Photovoltaic Panels Study Unit

• Electrical supply 220 V -

Weights and dimensions of Photovoltaic Panels Study Unit

• Dimensions: 660x450x200 h mm.
• Unit weight: 16 kg.
