Multivariable Coupled Tanks

Product Description

Multivariable Coupled Tanks

Experiments

1. Calibration of transducer and actuator circuits
2. System dynamics in process systems
3. Design and operation of analogue proportional, proportional + integral, or proportional + integral +
4. differential control controllers
5. Steady-state errors and closed-loop transient responses
6. Ziegler/Nichols controllers tuning rules
7. Multivariable   control
8. Step-change   tuning
9. State   feedback
10. Flow   control
11. The flexible design of the equipment allows the user to develop many other analysis and control exercises to suit their needs. It is good for extended or advanced control experiments, and is ideal for student project work.
