Ignition System

Ignition System simulator shows how modern  Ignition System operate.All relative signals, such as the output of Hall sensor,knock sensor output, engine speed, the refrigerator temperature, MAP output, A/D input, voltage and current of initial and secondary ignition, stroboscope trigger, end to test points.

The experiments covered by the Ignition System are:

• Direct ignition activation system
• Different spark types analysis
• Dwell timing and control
• MAP sensor characteristics
• Cooling sensor operation
• Knock sensor characteristics
• Constant current for various engine speeds
• Ignition System operation at various conditions of speed, load and engine temperature
• Ignition time and dwell measurements
• Operation of the Ignition System with fuel electronic injection
