Hydronic Balancing Of Radiators Unit

Product Description

Hydronic Balancing Of Radiators

Specification of Hydronic Balancing of Radiators

1. Trainer for heating and plumbing
2. 6 radiators with thermostatic valve, bleed valve and adjustable lock shield valve
3. Expansion vessel, safety group according to overflow valve
4. 5 rotameters
5. 1 surface thermometer for temperature measurement at radiator inlets and outlets
6. Water connections using quick-release couplings, diameter inside 13mm, for optional connection to an external heating circuit

Technical Data

Pump

1. Power consumption: 60W
2. Max. Flow rate: 60L/min
3. Max. Head: 4m
4. 6 balancing valves: PN 16

Measuring Ranges

1. Flow rate: 1x 30...320l/h, 4x 50...640l/h
2. Temperature: 1x -50...300°
