Gain And Offset Adjust

Product Description

Gain And Offset Adjust

Gain And Offset Adjust allows the proportional adaptation of the external signals to the normal voltages used in the automatic control systems.

Technical features of Gain And Offset Adjust

1. Power supply: +15 V ; 0 V ; 15 V
2. Voltage interval of the input signal: Â50 V, ..., +50 V
3. Adjustable level through the setting of the gain: 0 ....1, 0 .... 10, 0 .... 100
4. Attenuation of the pulse signals.
5. Time constants: 0,1 .... 10 ms ; 10 .... 100 ms
6. Offset voltages that can be connected: 10 V .... +10 V
7. Coarse setting through rotary switches.
8. Potentiometer fine setting.
