Front Axle Model

Product Description

Description:

Front-Axle Model for adjustments with rack and pinionsteering.  Representation of restoringforces. The training stand has angle indicator which can be positioned atvarious locations. All functions can be changed without tools via eccentricdisks, knurled nuts and quick release closures.

The following settings are possible:

1. Toe in

2. Toe out

3. Toe-angle

4. Positive camber

5. Negative camber

6. Spread

7. Follow-up

8. Change of the steering trapezoid


Technical Data

1. Dimensions: 167 x 70 x 156 cm, 130 cm

2. Weight: approx. 40 kg
