Flow Boiling Demonstration Unit

Product Description

Description of DIDAC Flow Boiling Demonstration Unit

The Flow Boiling Demonstration Unit is a floor-mounted unit designed to provide a visual demonstration of the flow boiling processes that can occur inside the vapour generating tubes of practical plant such as refrigeration, steam, chemical and food processing systems.

Experimental Capabilities of Flow Boiling Demonstration Unit

Demonstration of a heating process accompanied by vapour formation within a tube, including

Demonstration of two phase flow with increasing vapour content

Demonstration of effect of air in condensers

Specification of Flow Boiling Demonstration Unit:

Floor mounted, vertical, glass, concentric tube heat exchanger for the observation of all stages of heat transfer as a pure substance changes from sub-cooled liquid to superheated vapour.
