Data Acquisition System

Product Description

Description of Data Acquisition System

This unique and compact Data Acquisition System is an essential accessory for the Universal Vibrations Apparatus experiments. When connected to the relevant experiment and its sensors, the system allows measuring, capturing, storing and analysing of experiment data.

Experiment software supplied with the apparatus simulates an oscilloscope, allowing parameters such as phase angle, excitation frequency and displacement to be viewed. The parameters are fed into the system via the experiment sensors, i.e. proximity sensor, LVDT. Data Acquisition System is quick and easy to set up and connects to the host pc using a USB connection. The experiment transducers are wired into the using front mounted BNC sockets.

Specification of Data Acquisition System

1. PC Data Acquisition system for data capture and storage of inputs from experiments within the Universal Vibrations Apparatus
2. Can be used with other HVT range of experiments with suitable sensor outputs
3. To accept inputs of frequency and displacement
4. Software for results analysis
5. To incorporate USB port(s) for computer connection
6. To operate from USB supply voltage
7. All connection leads included
