Compressors Test Bench

Product Description

Compressors Test Bench

The Compressors Test Bench allows to experimentally characterize a wide range of air compressors, in a work field from 0 to 500 Nm3/h as regards the flow rate and from 0 to 10 bar as regards the pressure. The high precision of the sensors installed in the Test Bench allows to perform accurate and trustable research experiments within the whole work field. The Compressors Test Bench is extremely versatile: in fact, it has been designed to allow to choose and mount compressors of different size and type, coupled to different electric motors, selected by the user. The frame of Compressors Test Bench is very strong and has to be fixed to the floor; the bench is completely made of corrosion-proof materials. The electric control and command board allows to operate in manual mode, by personal computer or by external board. An user manual is supplied with the equipment.

Required services of Compressors Test Bench

• Electric supply: 380V, three-phase + neutral, 50/60 Hz; up to 18 kW.
• Water supply: 1000 l/h.

Weight and dimensions of Compressors Test Bench

• Weight: 350 kg approx
• Dimensions: 3000x1000x2000 h mm
