Compact Reciprocating Pump Test Set Fixed Speed

Description of Compact Reciprocating Pump Test Set Fixed Speed

Compact Reciprocating Pump Test Set Fixed Speed is a self contained bench top unit for studying the reciprocating pump flow rate vs head at a fixed speed. The unit consists of a storage tank and a reciprocating pump with a belt and pulley drive and motor on a steel base, and measuring

Experiments of Compact Reciprocating Pump Test Set Fixed Speed

1. Flow rate vs head.
2. Effect of pulse chamber.

Technical Data of Compact Reciprocating Pump Test Set Fixed Speed

Pump ratings at 300 rpm.

1. Maximum flow rate : 15 lpm.
2. Maximum head : 30 m water.

Pump accessories

1. Pressure relief valve.
2. Pulse chambers with vent valves.

Measuring instruments :

1. Pressures : Pressure gauges at pump suction and discharge.
2. Flow rate : Water meter.

Power supply : 220V 1Ph 50 Hz. Other power supply is available on request.
