Column Buckling

Description of Column Buckling

The Column Buckling equipment is used for studying strut buckling under load. Column Buckling is to be used with Universal Structural Frame or Universal Base Frame. The top frame has a loading screw which pushes a cylindrical strut support sliding in a bushing. The bottom frame has a load cell and a cylindrical strut support in a socket. Each strut has end conditions for knife edge or built in. The load reading is by an indicator. A small lateral load is applied by means of a pulley and a weight hanger. A dial indicator measures the lateral deflection.

Technical Data of Column Buckling

• Top support with a loading screw : 1 ea.
• Bottom support with a load cell : 1 ea.
• Force indicator : 1 ea.
• Strut specimens :
• Material : 1 ea. mild steel, brass, aluminum.
• Strut supports :
• Built in : 2 ea.
• Knife  edge : 2 ea.
• Horizontal load hanger with pulley : 1 set.
• Weights : 1 lot.
• Dial indicator : 1 ea.
• Power supply : 220V 1Ph 50Hz.
