Central Climatization System

Product Description

Central Climatization System

The Central Climatization System simulates the indoor air treatment for buildings such as hospitals, schools, hotels.Two fans - one at the air inlet, one at the air outlet - generate an air flow passing in an air distribution system, which has theshape of an H. Electrically or manually operated gates allow simulating the fresh air inlet and the presence of one user.Two heat exchangers are assembled inside the air distribution system which allow varying the cooling or heating capacities.A chiller complete with a reverse cycle valve feeds the two exchangers with hot or cold water according to the selectedcycle.The unit is supplied with a manual that describes each component of the system, installation and utilization procedures.

Experiments of Central Climatization System

• Study of air flow and air flow measurements.
• Study of a chiller and its functioning as a heat pump
• Summer air conditioning
• Winter air conditioning
• Influence of the air flow
• Influence of fresh air inlet

Required services of Central Climatization System

• Electrical power supply: 380V, three phase and ground, 50/60 Hz, 2.5 kW.
• Water supply: from mains, to fill the tank and the circuit.

Weight and dimensions of Central Climatization System

• Weight: empty 500 kg.
• Dimensions: 3000x2500x2000 h mm.
