Camshaft Adjustment

Product Description

Description:

1. Drive of theoutlet camshaft via a rotary button

2. Drive of theinlet camshaft via a control chain

3. Holding theoutlet camshaft with the help of a set screw

4. With the helpof a push bar, the hydraulic piston can be displaced and the adjustment of theinlet camshaft read off directly on a scale

5. The functionof the chain tenser is easily recognised

6. The hydraulicpiston and the piston of the solenoid valve are cut away
