Building Automation In Heating And Air Conditioning Systems

Product Description

Building Automation In Heating And Air Conditioning Systems

Heating and air conditioning technology is a key topic in building services engineering. For the control and monitoring of heating and air conditioning systems DDCs (Direct Digital Control) or PLC air conditioning controllers are usually used in building services engineering. The controller is adjusted to the respective tasks by programming, making additional cabling unnecessary.

Learning Objectives/Experiments

1. Operation and programming of a DDC
2. Effects of temperature changes on the operating behaviour of a
3. Heating system
4. Air conditioning system
5. Fault finding in a
6. Heating system
7. Air conditioning system
8. Safety devices

Specification

1. Experimental unit from the practical series for the training of mechatronics engineers for refrigeration
2. Operation and programming of a DDC for heating and air conditioning systems
3. Process schematic of the simulated heating system with 2 boilers, 2 heating lines and water heating
4. Process schematic of the simulated air conditioning system with selectable outer air and recirculating operation
5. Programmable DDC with selection and display of the operating states and error simulation
6. Process schematics with bargraph displays and lamps for operating states of the actuators
7. 16 potentiometers in the process schematics to adjust simulated temperatures
8. Process schematics on the front panel
