Auto Electrical System

Product Description

Description:

1. Selfcontained, fully operational Automotive Electrical System, manufactured usingreal components.

2. Demonstrationboard using original components including headlights, side lights, indicatorsand spotlights. The alternator is motor driven via a special controller todemonstrate the charging circuit.

3. Afully operational 12 V DC starter motor and a contact breaker ignition are alsoincluded on the board.

4. Thesystem is powered by a 12 V DC battery for the electrical circuit and by 240 VAC for the speed controlled motor.


Main Technical Data:

1. Fully operational auto electrical trainermanufactured using original components

2. Based on a generic auto electrical system,complete with charging, lighting, contact breaker ignition systems and startermotor

3. Components include: Alternator (motordriven), Headlights, Side lights (front & rear), Indicators, Brake lights,CB distributor (motor driven), HT ignition coil, 4x Spark plugs, Inertiastarter motor, Start solenoid, Control dash panel, Relays and Battery isolator

4. Variable speed control for alternator

5. Rotating parts covered by mesh guards

6. Board mounted in a vertical bench frame

7. Powder coated paint finish


Supply Voltage:

1. 12 V and 240 V


Dimensions:

1. Length 675 mm, Width 950 mm, Height 860 mm

2. Weight: 62 kg
