Assembly Station Pipes and Valves and Fittings

Product Description

Assembly Station: Pipes and Valves and Fittings

Specification Of Assembly Station: Pipes and Valves and Fittings

• Assembly exercise for engineering training
• Piping network comprising pipe bends, elbows, T-pieces and transitions in nominal
• Pipe connections via flanges or cutting ring screw fittings
• Standard commercially available flanged fittings: shut-off valve, non-return valve, strainer, condensation Drain, inspection glass, ball valve, gate valve
• Ball valve with cutting ring screw fitting
• Pressure vessel with manometer, connection via
• Mobile frame for mounting of pipe network
• Connection to water supply via hose with coupling

Technical Data

Flange fittings

• Grey cast iron
• Ball valve with cutting ring screw fitting
• Brass, nickel-plated
• Nominal pressure: PN25
• Nominal size: G1/2"
• Manometer: 0...4bar
