Assembly And Maintenance Exercise Refrigeration Unit

Product Description

Assembly And  Maintenance Exercise Refrigeration

Specification of Assembly & Maintenance Exercise: Refrigeration

1. Assembly project for the training of mechatronics engineers for refrigeration
2. Setup of a refrigeration system with refrigeration chamber from a complete set of components
3. Temperature control via thermostat
4. Air-cooled condensing unit with compressor
5. Refrigeration chamber with integrated show case evaporator and fan
6. Refrigeration chamber with large sight window
7. Assembly panel to mount the refrigeration and electrical components
8. Electrical assembly in accordance with the circuit diagram
9. Easy pipe working of the refrigeration circuit using bolted pipe joints
10. Workbench with drawers to store the components

Technical Data

Condensing unit

1. Power consumption: 190W
2. Refrigeration capacity: 373W at 5C evaporation
3. Temperature
4. Receiver: approx. 1L

Show case evaporator

1. Capacity: 50W at t0=-6C, T=8K
2. Transfer area: 1,06m
3. Refrigeration chamber with sight window
4. L x w x h: 480x280x390mm
5. Aluminium assembly panel
6. L x w: 710x500mm
7. Thermostatic expansion valve, adjustable
8. Thermostat, adjustable: -30...15C
