Analogue To Digital Converters

Product Description

Analogue To Digital Converters

This board allows the study of the operating principle and of the main characteristics of analogue-to-digital converters. The board is divided in 2 sections: in the first one a discrete component realization is provided of a ramp A/D counter converter, while in the second section there is a monolithic converter. The first section is used to highlight the operating principle of an A/D converter, while the second one is mainly used to analyse the operating modes and the characteristics of the converters that are commercially available.

The board is supplied complete with a set of stackable, plug-in cables of suitable lengths and colours and with a training manual.

Power supply: ± 15 Vdc, 100 mA and + 5Vdc, 200mA

Experiments of Analogue To Digital Converters
