Air Conditioning And Ventilation Unit

Product Description

Air Conditioning And Ventilation Unit

Specification of Air Conditioning And Ventilation Unit

1. Practice-oriented air conditioning and ventilation system with 3 independent system components: main unit, condensing unit, steam generator
2. Manual or automatic operation via plc air conditioning controller
3. Main unit with air duct, fan, air conditioning system
4. Air conditioning system with direct evaporator as air cooler, electric air heater, humidification
5. Hoses connect direct evaporator to condensing unit, humidification to steam humidifier
6. Air duct from hot galvanised sheet with sight window and pressure measurement connections to record pressure curves
7. Air duct with filter, multi-leaf damper, ceiling vent, protective grating, ventilation grille, fire protection flap, inspection flap, sound insulation link, smoke detector
8. Standard connection piece to connect to external ventilation system

Technical Data

1. Fan, speed-controlled 0...1500min-1
2. Max. Volumetric air flow rate: 2500m³/h
3. Max. Pressure level: 715Pa
4. Drive motor power: 1,1kw
5. Air heater, 4 stages: 0-5-10-15-20kw
6. Air cooler (direct evaporator), cooling capacity: 27kW

Condensing Unit

1. Rated cooling capacity: approx. 16,6kw at 7.2/32°c
2. Power consumption: approx. 7,4kW at 7.2/32°C

Steam Humidifier

1. Steam capacity: 10kg/h
2. Power consumption: 7,5kw
3. External standard connection piece: 400x400mm

Duct Cross-Sections

1. Bottom: wxh: 630x630mm, top: wxh: 358x358mm
2. Inclined tube manometer: 0...750Pa
