Air Conditioning And Climatization Study Unit

Product Description

Air Conditioning And Climatization Study Unit

The Air Conditioning And Climatization Study Unit has been developed for insertion in the most advanced educationalsubjects.Simplicity and clearness are the fundamental requirements that permit the teacher and students to operate without having todeal first with complicated utilization procedures.The working principle of the apparatus is the following an air flow generated by a centrifugal fan enters a tunnel passingthrough a fluid thread rectifier. As the air passes through the tunnel it undergoes a series of treatments, until it arrives in thelast chamber, which represents the environment to be conditioned. The flow is pre-heated, then moisturized by steam diffusers it is cooled through the evaporator and sent to the final chamber. Before this last stage it may be re-heated andmoisturized by water diffusers, to experiment on heating environments and to have the opportunity to vary as manyparameters as possible for a complete study on air conditioning.

Required services of Air Conditioning And Climatization Study Unit

• Electric supply: 380 V three-phase 50/60 Hz, 9 kW

Weight and dimensions of Air Conditioning And Climatization Study Uni

• Dimensions: 2450 x 480 x 1400 h mm
• Weight: 230 kg
